JumpAndDrillShapePattern LaserPulseSkew

Get or Set the pulse timing skew between the laser 1 modulation signal and the laser 2 modulation signal or the time delay between the two modulation signals.

public float LaserPulseSkew {get;Set}

Return value

float

The delay between laser modulation signals

Example

Copy

 JumpAndDrillShapePattern jumpandDrillPattern = new JumpAndDrillShapePattern();

 jumpandDrillPattern.PulseWidth1 = (float)2.5;
 jumpandDrillPattern.PulseWidth2 = (float)2.5;
 jumpandDrillPattern.LaserModulationDelay = 14;

 jumpandDrillPattern.LaserPulseSkew = 1;

 jumpandDrillPattern.LaserOffLag = 2;
 jumpandDrillPattern.UsePulseBurstMode = false;
